Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Color | Natural |
| Cover Locking | Latch |
| Cover Mounting | Hinged |
| Dimensions | 12 x 10 x 6 In. (305 x 254 x 152 mm) |
| Enclosure Mounting | Wall Mount |
| IP Rating | IP65 |
| Material | Aluminum |
| NEMA Rating | NEMA 3 ; NEMA 4X ; NEMA 12 ; NEMA 13 |
| Size | Medium |
| Size, Approximate Depth | 6" (152mm) |
| Size, Approximate Height | 12" (305mm) |
| Size, Approximate Width | 10" (254mm) |
| Special Features | Oil-Resistant Gasket |
| Type | Junction Box |
| UPC Code | 78351056350 |
Overview
APPLICATION
Lightweight enclosures protect components and controls in indoor applications.
SPECIFICATIONS
FINISH
Enclosures are unpainted. Cover and sides of body have smooth brushed finish.
